The SS Handrail Bracket is a heavy-duty structural support engineered to anchor flat-bottom handrails securely to walls, steps, or floor surfaces across modern architectural railing installations. Built to satisfy rigorous safety and accessibility standards, this versatile bracket provides unwavering stability and structural integrity for staircases, balconies, ramps, and pedestrian walkways.
The assembly features a circular mounting floor flange equipped with three countersunk holes for flush, heavy-duty fastening, an angled support stem, and a flat rectangular saddle plate with two pre-drilled holes designed to screw directly into the underside of timber or metallic handrail profiles. Key technical dimensions include a total vertical height offset (A) of 85 mm, a horizontal extension projection (B) of 62 mm from the post centerline to the saddle, and a mounting flange outer diameter (C) of 63 mm. Available in premium AISI 304 (general interior use), AISI 316 (marine/outdoor environments), and Duplex 2205 (high-strength/extreme corrosion resistance) stainless steel with brushed satin or reflective mirror polished finishes, these core handrail fittings deliver reliable performance and modern aesthetic appeal in both residential and commercial spaces.
|
Category |
Part NO. |
Fit for Tube
(mm) |
A (mm) |
B (mm) |
C (mm) |
Material |
Surface |
Place of Production |
| Handrail Brackets |
D0100 |
Flat
|
85 | 62 |
63 |
AISI 304,316 or Duplex SS 2205 |
Satin or Mirror polished |
Shandong, China |
1. Manufacturing Process: Investment Casting + Precision Machining+Polishing
2. Application Scenario: Hotel, Villa, Apartment, Office Building, Hospital, School, Mall, Sports Venues, Leisure Facilities, Supermarket, Park, Bathroom, Outdoor, Exterior, Entry, Hall, Staircase, Gym
3. Use Place: Bridge Railings / Handrails, Deck Railings / Handrails, Porch Railings / Handrails, Stair Railings / Handrails
4. Installation Location: Flooring / Wall
5. Design Style: Contemporary, Modern, European, Craftsman
6. Certificate: ISO9001:2015
7. Engineering Solution Capability: Graphic Design, 3d Model Design, Total Solution For Projects
8. Certificates: Material Certificates, Dimension Inspection Certificate
9. Lead Time : 60days batch production after handrail bracket samples approved
10. Warranty Service: 1 Year
11. After-sales Service: Online Technical Support, Return And Replacement
Q1: What type of handrails are compatible with this SS Handrail Bracket?
A: This bracket features a flat rectangular saddle plate with two fixing holes, making it ideal for mounting flat-bottom wooden, steel, or aluminum handrails.
Q: What are the exact structural dimensions of this bracket?
A: Based on the technical engineering specifications:
Height / Vertical Offset (A): 85 mm (from the mounting flange base to the centerline of the horizontal arm)
Projection / Extension (B): 62 mm (from the vertical support stem centerline to the saddle plate)
Flange Outer Diameter (C): 63 mm circular base with 3 countersunk mounting holes.
Q: How do I select the right stainless steel grade (304, 316, or 2205) for my project?
A: Choose the material grade according to the installation environment:
AISI 304: Best suited for dry indoor environments, interior residential stairwells, and commercial building corridors.
AISI 316: Ideal for general outdoor applications, exterior stairways, decks, and humid indoor areas like pools.
Duplex 2205: Engineered for harsh marine environments, coastal properties exposed to salt air, and heavy chemical industrial settings requiring high structural strength and maximum corrosion resistance.
Q: What surface finishes are available for these handrail fittings?
A: These brackets are available in a contemporary brushed satin finish (ideal for hiding fingerprints in high-traffic interior spaces) and a reflective mirror polished finish (offering enhanced smooth surface protection against environmental elements in outdoor settings).
